Mbemba Stainless is a well-respected manufacturer and supplier of top-notch **Stainless Steel Sockets** located in Kinshasa, Congo. This company has built a solid reputation for crafting precision-engineered pipe fittings that guarantee reliable, leak-proof, and long-lasting connections across various industrial systems. Using high-quality stainless steel and cutting-edge technology, these sockets adhere to international standards for strength, corrosion resistance, and overall performance. Mbemba Stainless caters to a range of industries, including petrochemical, power generation, oil and gas, water treatment, and marine engineering, both in Congo and on the global stage, providing products that ensure durability, safety, and efficient fluid handling.
Typically, Stainless Steel Sockets are made from grades like SS 304, 304L, 316, and 316L, which include chromium (18–20%), nickel (8–12%), and molybdenum (2–3% in 316). These elements contribute to their exceptional corrosion resistance, tensile strength, and durability. The sockets boast a tensile strength between 515–620 MPa and a yield strength of 205–290 MPa, along with impressive ductility and toughness. Their strong mechanical properties make them perfect for high-pressure, high-temperature, and corrosive fluid systems.
| Grades | 201, 202, 304, 304L, 304H, 309S, 309H, 310S, 310H, 316, 316TI, 316H, 316L, 316LN, 317, 317L, 321, 321H, 347, 347H, 904L |
| Type | Seamless / Welded / Fabricated |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Size | ½”NB to 48″NB in |
| Schedule | Sch 10s, 40s, 80s, 160s, XXS. |
| Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43. |
| SS | 304 | 304N | 304LN |
|---|---|---|---|
| Ni | 8 – 11 | 8 – 11 | 8 – 11 |
| Fe | Balance | ||
| Cr | 18 – 20 | 18 – 20 | 18 – 20 |
| C | 0.08 max | 0.08 max | 0.035 max |
| Si | 0.75 max | 0.75 max | 0.75 max |
| Mn | 2 max | 2 max | 2 max |
| P | 0.040 max | 0.040 max | 0.040 max |
| S | 0.030 max | 0.030 max | 0.030 max |
| N | 0.10 – 0.16 | 0.10 – 0.16 | |
| Density | 8.0 g/cm3 |
| Melting Point | 1400 °C (2550 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
Contact us to get a quick quote for your requirement.
Our stainless steel sockets are manufactured to the highest quality. Each piece is thoroughly tested in terms of hardness, chemical analysis, PMI testing, flattening, as well as micro and macro test, pitting resistance, flaring, and IGC tests. We give documentation that includes commercial invoice, packing lists, Certificated of Origin, and a letter of guarantee for everything that’s put under transparency. To spice things, we have third-party inspection certificates that affirm the customer’s satisfaction and product quality.
Stainless steel sockets are highly resistant to corrosion due to their chromium content, but they may corrode under extreme conditions, such as exposure to harsh chemicals or seawater. Regular maintenance ensures longevity.
Stainless steel sockets can attract magnets if they are made from ferritic or martensitic stainless steel, which contain magnetic properties. However, austenitic stainless steel, commonly used, is non-magnetic.
Yes, stainless steel sockets can be recycled after use. Stainless steel is a highly recyclable material, and recycling it helps reduce environmental impact while conserving valuable resources.
Yes, stainless steel sockets can be used for underground applications. Their corrosion resistance makes them suitable for harsh environments, ensuring durability and performance in buried or underground installations.
You’ll find Stainless Steel Sockets commonly used in **plumbing, oil and gas pipelines, chemical plants, refineries, water treatment systems, and food processing industries**. They create a robust, secure, and leak-proof connection between pipes, ensuring smooth fluid and gas flow. Thanks to their corrosion resistance, heat tolerance, and mechanical strength, they are well-suited for both high-pressure and sanitary applications. Additionally, Stainless Steel Sockets are favored in marine and offshore industries for their ability to endure harsh environments, providing reliable and long-lasting performance even in challenging conditions.
